Collection: Forward Facing Sonar Batteries
Batteries in this section are most commonly used with Forward Facing Sonar. NMC are made for portable shuttles and ice fishing units only. LiFePO4 batteries are made for boats or portable kits (Shuttles and Ice Fishing) and can be charged onboard with the proper onboard waterproof charger.
*Operating times are according to manufacturer listed amp draws. Times may vary based on conditions such settings, temperature and installation.
Operating Time Chart
| Working Voltage | MFG Amp Draw | 20Ah LiFePO4 | 30Ah LiFePO4 | 19AH NMC | 32Ah NMC | 52Ah NMC | 60AH LiFePO4 | 80Ah LiFePO4 | 100AH LiFePO4 | 130Ah LiFePO4 | 160Ah LiFePO4 | 16V 50Ah | 16V 80AH | |
| Usable Amp Hours | 20 | 30 | 19 | 32 | 52 | 60 | 80 | 100 | 130 | 160 | 50 | 80 | ||
| Usable Watt Hours | 256 | 384 | 281.2 | 473.6 | 769.6 | 768 | 1024 | 1280 | 1664 | 2048 | 800 | 1280 | ||
| Humminbird | MFG Amp Draw | 20Ah LiFePO4 | 30Ah LiFePO4 | 19AH NMC | 32Ah NMC | 52Ah NMC | 60AJ LiFePO4 | 80Ah LiFePO4 | 100AH LiFePO4 | 130Ah LiFePO4 | 160Ah LiFePO4 | 16V 50Ah | 16V 80AH | |
| 7" Screen/Mega Live | 10.8V-20V | 1.8 | 11.9 | 17.8 | 13.0 | 21.9 | 35.6 | 35.6 | 47.4 | 59.3 | 77.0 | 94.8 | 37.0 | 59.3 |
| 8" Screen/Mega Live | 10.8V-20V | 2.2 | 9.7 | 14.5 | 10.7 | 17.9 | 29.2 | 29.1 | 38.8 | 48.5 | 63.0 | 77.6 | 30.3 | 48.5 |
| 9" Screen/Mega Live | 10.8V-20V | 2.7 | 7.9 | 11.9 | 8.7 | 14.6 | 23.8 | 23.7 | 31.6 | 39.5 | 51.4 | 63.2 | 24.7 | 39.5 |
| 10" Screen/Mega Live | 10.8V-20V | 3 | 7.1 | 10.7 | 7.8 | 13.2 | 21.4 | 21.3 | 28.4 | 35.6 | 46.2 | 56.9 | 22.2 | 35.6 |
| 12" Screen/Mega Live | 10.8V-20V | 4 | 5.3 | 8.0 | 5.9 | 9.9 | 16.0 | 16.0 | 21.3 | 26.7 | 34.7 | 42.7 | 16.7 | 26.7 |
| 15" Screen/Mega Live | 10.8V-20V | 5 | 4.3 | 6.4 | 4.7 | 7.9 | 12.8 | 12.8 | 17.1 | 21.3 | 27.7 | 34.1 | 13.3 | 21.3 |
| Garmin | MFG Amp Draw | 20Ah LiFePO4 | 30Ah LiFePO4 | 19AH NMC | 32Ah NMC | 52Ah NMC | 60AJ LiFePO4 | 80Ah LiFePO4 | 100AH LiFePO4 | 130Ah LiFePO4 | 160Ah LiFePO4 | 16V 50Ah | 16V 80AH | |
| 7" Screen/Livescope | 9V-18V | 2 | 10.7 | 16.0 | 11.7 | 19.7 | 32.1 | 32.0 | 42.7 | 53.3 | 69.3 | 85.3 | 33.3 | 53.3 |
| 9" Screen/Livescope | 9V-18V | 2.25 | 9.5 | 14.2 | 10.4 | 17.5 | 28.5 | 28.4 | 37.9 | 47.4 | 61.6 | 75.9 | 29.6 | 47.4 |
| 10" Screen/Livescope | 9V-18V | 3 | 7.1 | 10.7 | 7.8 | 13.2 | 21.4 | 21.3 | 28.4 | 35.6 | 46.2 | 56.9 | 22.2 | 35.6 |
| 12-13" Screen/Livescope | 9V-18V | 4 | 5.3 | 8.0 | 5.9 | 9.9 | 16.0 | 16.0 | 21.3 | 26.7 | 34.7 | 42.7 | 16.7 | 26.7 |
| 16" Screen/Livescope | 9V-18V | 5 | 4.3 | 6.4 | 4.7 | 7.9 | 12.8 | 12.8 | 17.1 | 21.3 | 27.7 | 34.1 | 13.3 | 21.3 |
| Lowrance | MFG Amp Draw | 20Ah LiFePO4 | 30Ah LiFePO4 | 19AH NMC | 32Ah NMC | 52Ah NMC | 60AJ LiFePO4 | 80Ah LiFePO4 | 100AH LiFePO4 | 130Ah LiFePO4 | 160Ah LiFePO4 | 16V 50Ah | 16V 80AH | |
| 7" Screen/Active Target | 10.8V-17V | 3.2 | 6.7 | 10.0 | 7.3 | 12.3 | 20.0 | 20.0 | 26.7 | 33.3 | 43.3 | 53.3 | 20.8 | 33.3 |
| 9-10" Screen/Active Target | 10.8V-17V | 3.5 | 6.1 | 9.1 | 6.7 | 11.3 | 18.3 | 18.3 | 24.4 | 30.5 | 39.6 | 48.8 | 19.0 | 30.5 |
| 12" Screen/Active Target | 10.8V-17V | 3.8 | 5.6 | 8.4 | 6.2 | 10.4 | 16.9 | 16.8 | 22.5 | 28.1 | 36.5 | 44.9 | 17.5 | 28.1 |
| 16" Screen/Active Target | 10.8V-17V | 4.5 | 4.7 | 7.1 | 5.2 | 8.8 | 14.3 | 14.2 | 19.0 | 23.7 | 30.8 | 37.9 | 14.8 | 23.7 |
